High Frequency PCB

EdgePCBA provides high-frequency PCB manufacturing. High Frequency PCBs are specially designed printed circuit boards that can transmit signals over 500 MHz, or at frequencies above 1 GHz depending on the application. These boards use specialized materials with low dielectric loss, low dielectric constant (Dk), and minimal signal distortion, making them ideal for high-speed and high-frequency electronic applications.

Flexible PCB

Flexible PCB

HDI PCB

HDI PCB

High Frequency PCB

High Frequency PCB

High Speed PCB

High Speed PCB

Rigid-flex PCB

Rigid-flex PCB

Metal PCB

Metal PCB

Ceramic PCB

Ceramic PCB

High-Frequency PCB Manufacturing Services

High-frequency PCBs are essential for applications requiring fast signal flow rates and high-speed communication. At [Your Company Name], we specialize in high-frequency PCB manufacturing that meets the demands of today’s advanced RF, microwave, and high-speed digital applications.



Why Choose Our High-Frequency PCB Services?

  • Advanced Materials: EdgePCBA utilizes premium high-frequency laminates such as Rogers, Taconic, Arlon, and PTFE to ensure low dielectric loss and high thermal stability.
  • Precision Fabrication: Our manufacturing processes support tight impedance control, minimal signal loss, and consistent performance across all high-frequency ranges.
  • Custom Solutions: Whether you're designing for aerospace, telecommunications, automotive radar, or medical devices, we provide tailored solutions to meet specific RF requirements.
  • Capabilities Include: Frequency range up to 40 GHz and above; Controlled impedance ±10% or better; Low Dk (2.2 to 3.8) and low Df materials; Multilayer high-frequency board production; Mixed dielectric designs (Hybrid PCBs)
  • Rigorous Testing & Quality Control: We conduct thorough electrical testing, dimensional checks, and material validation to ensure every board meets your specifications.

Why Use High Frequency PCBs?

Key Reasons to Use High-Frequency PCBs:

  • Superior Signal Transmission: High-frequency PCBs use materials with low dielectric constant (Dk) and low dissipation factor (Df), ensuring minimal signal loss and faster transmission speeds, critical for RF and microwave circuits.
  • Precise Impedance Control: Applications like radar, satellite, and 5G systems require strict impedance matching. High-frequency PCBs support tight impedance control, reducing signal reflections and improving overall circuit performance.
  • Low Dielectric Loss: The advanced laminates used in high-frequency PCBs have excellent electrical characteristics, reducing dielectric loss and maintaining signal clarity even at high frequencies.
  • High Thermal and Chemical Stability: These PCBs are built from materials like PTFE or ceramic-filled laminates, which offer superior stability in harsh environments—ideal for aerospace, automotive radar, and industrial sensors.
  • EMI/RFI Management: With proper layer stack-up and material selection, high-frequency PCBs help minimize electromagnetic interference and radio-frequency interference, ensuring compliance with industry standards.
Get A Quote

ASSEMBLY CAPABILITIES

Assembly Capabilities for PCBs

Stencil Size Range

29inch*29inch

SMT

Position accuracy: 25um
Components size:0201--150mm
Max.PCB Size:680mm*500mm
MinPCB size:50mm*50mm
Min.PCB Thickness:0.3mm-- 6mm
Min.IC Pitch: 0.30mm

Wave-Solder

Max.PCB width:450mm Min.PCB width:no Limited Component height: Top 120mm/Bottom 15mm

Min.BGA pitch

0.008"

Max.BGA Size

74mm x74mm

BGA Ball Pitch

1.00mm(Min);3.00mm(Max)

BGA Ball Diameter

0.40mm(Min);1.00mm(Max)

QFP Lead Pitch

0.38mm(Min);2.54mm(Max)

For further discussion about PCB Assembly, please contact us.

MATERIALS

Diversified PCB Assembly Materials You Can Choose

  • FR-4
  • Glass epoxy
  • FR4 High Tg
  • Rohs compliant
  • Aluminum
  • Rogers
  • FR-4
  • Glass epoxy
  • FR4 High Tg
  • Rohs compliant
  • Aluminum
  • Rogers
Get A Quote
our pcbs

LAYERS

Customizable PCB Boards Up to 32 Layers

Get A Quote
our pcbs

Assemble Your PCB Now!

Don't hesitate to reach out if you require any help or have specific customization requirements that we can cater to.
